Smart Pressure Pump Controller IEPC3A-2200 (SP)

Description

Specifications

Technical parameters:

1. Start-up pressure range: Adjustable 0.5-6.0 bar

2. Maximum rated current: 30A

3. Maximum power: 2.2KW

4. Permissible maximum pressure: 10 bar

5. Rated voltage: 100V or 240V

6. Frequency: 50/60Hz

7. Maximum Medium Temperature: 0~100 degrees C

8. Protection Level: IP65

Description:

1. Automatic smart control of pump operation and shutdown.

2. Stop pumping automatically in case of water shortage.

3. Call will start automatically after a power failure.

4. Manual mandatory startup.

5. Over-pressure protection, system pressure more than 10 bars automatically stop the pump work.

6. Water shortage self-start, the time interval of self-start is 1 minute, 30 minutes, 1 hour, and then 1-hour cycle.

7. It can be configured according to user’s requirements.
